Creating an RDS instance with CloudFormation

Matthew Casperson

Matthew Casperson

June 6, 2022 • 2 mins

Amazon Relational Database Service (RDS) implements managed databases supporting a number of platforms such as MySQL, MariaDB, Oracle, Postgres, and SQL Server. Almost every custom application requires persistent data storage, and RDS provides a convenient, scalable, and highly available solution.

In this post, you learn how to deploy an RDS instance with a CloudFormation template.

An RDS CloudFormation template

The template below deploys an RDS instance into a new VPC with 2 private subnets:

Parameters:
  Tag:
    Type: "String"
  DBUsername:
    Type: "String"
  DBPassword:
    Type: "String"

Resources:
  VPC:
    Type: "AWS::EC2::VPC"
    Properties:
      CidrBlock: "10.0.0.0/16"
      Tags:
      - Key: "Name"
        Value: !Ref "Tag"

  SubnetA:
    Type: "AWS::EC2::Subnet"
    Properties:
      AvailabilityZone: !Select
        - 0
        - !GetAZs
          Ref: 'AWS::Region'
      VpcId: !Ref "VPC"
      CidrBlock: "10.0.0.0/24"

  SubnetB:
    Type: "AWS::EC2::Subnet"
    Properties:
      AvailabilityZone: !Select
        - 1
        - !GetAZs
          Ref: 'AWS::Region'
      VpcId: !Ref "VPC"
      CidrBlock: "10.0.1.0/24"

  RouteTable:
    Type: "AWS::EC2::RouteTable"
    Properties:
      VpcId: !Ref "VPC"

  SubnetGroup:
    Type: "AWS::RDS::DBSubnetGroup"
    Properties:
      DBSubnetGroupName: "subnetgroup"
      DBSubnetGroupDescription: "Subnet Group"
      SubnetIds:
      - !Ref "SubnetA"
      - !Ref "SubnetB"

  InstanceSecurityGroup:
    Type: "AWS::EC2::SecurityGroup"
    Properties:
      GroupName: "Example Security Group"
      GroupDescription: "RDS traffic"
      VpcId: !Ref "VPC"
      SecurityGroupEgress:
      - IpProtocol: "-1"
        CidrIp: "0.0.0.0/0"

  InstanceSecurityGroupIngress:
    Type: "AWS::EC2::SecurityGroupIngress"
    DependsOn: "InstanceSecurityGroup"
    Properties:
      GroupId: !Ref "InstanceSecurityGroup"
      IpProtocol: "tcp"
      FromPort: "0"
      ToPort: "65535"
      SourceSecurityGroupId: !Ref "InstanceSecurityGroup"

  RDSCluster:
    Type: "AWS::RDS::DBCluster"
    Properties:
      DBSubnetGroupName: !Ref "SubnetGroup"
      MasterUsername: !Ref "DBUsername"
      MasterUserPassword: !Ref "DBPassword"
      DatabaseName: "products"
      Engine: "aurora"
      EngineMode: "serverless"
      VpcSecurityGroupIds:
      - !Ref "InstanceSecurityGroup"
      ScalingConfiguration:
        AutoPause: true
        MaxCapacity: 16
        MinCapacity: 2
        SecondsUntilAutoPause: 300

Outputs:
  VpcId:
    Description: The VPC ID
    Value: !Ref VPC

The VPC, subnets, and route tables were described in a previous post. This template then places a number of additional resources into the VPC to support or create the RDS instance.

RDS instances need at least 2 subnets to achieve high availability. These subnets are grouped together in an AWSRDSDBSubnetGroup resource:

  SubnetGroup:
    Type: "AWS::RDS::DBSubnetGroup"
    Properties:
      DBSubnetGroupName: "subnetgroup"
      DBSubnetGroupDescription: "Subnet Group"
      SubnetIds:
      - !Ref "SubnetA"
      - !Ref "SubnetB"

Network access to the RDS instance is defined in a security group, represented by an AWSEC2SecurityGroup resource. This security group allows all outbound traffic, but doesn't specify any rules for inbound traffic. Inbound traffic rules are taken care of with another resource:

  InstanceSecurityGroup:
    Type: "AWS::EC2::SecurityGroup"
    Properties:
      GroupName: "Example Security Group"
      GroupDescription: "RDS traffic"
      VpcId: !Ref "VPC"
      SecurityGroupEgress:
      - IpProtocol: "-1"
        CidrIp: "0.0.0.0/0"

It's rare that a production database is accessible to public traffic. In fact, RDS solutions like Aurora Serverless (which you create next) are only accessible in a VPC:

You can't give an Aurora Serverless v1 DB cluster a public IP address. You can access an Aurora Serverless v1 DB cluster only from within a VPC.

To grant resources in the VPC access to the RDS instance, you create an ingress rule that grants network traffic to any resource that has been assigned the security group defined above. Allowing resources that share a security group to communicate with each other is a convenient way to group related resources without having to partition them in special CIDR blocks.

Ingress rules are represented by the AWSEC2SecurityGroupIngress resource:

  InstanceSecurityGroupIngress:
    Type: "AWS::EC2::SecurityGroupIngress"
    DependsOn: "InstanceSecurityGroup"
    Properties:
      GroupId: !Ref "InstanceSecurityGroup"
      IpProtocol: "tcp"
      FromPort: "0"
      ToPort: "65535"
      SourceSecurityGroupId: !Ref "InstanceSecurityGroup"

You now have everything in place to deploy the RDS instance, represented by the AWSRDSDBCluster resource. The example below creates a serverless Aurora instance:

  RDSCluster:
    Type: "AWS::RDS::DBCluster"
    Properties:
      DBSubnetGroupName: !Ref "SubnetGroup"
      MasterUsername: !Ref "DBUsername"
      MasterUserPassword: !Ref "DBPassword"
      DatabaseName: "products"
      Engine: "aurora"
      EngineMode: "serverless"
      VpcSecurityGroupIds:
      - !Ref "InstanceSecurityGroup"
      ScalingConfiguration:
        AutoPause: true
        MaxCapacity: 16
        MinCapacity: 2
        SecondsUntilAutoPause: 300

Conclusion

RDS provides a managed, scalable, and highly available database platform supporting a number of popular database providers.

This post built on our post describing VPCs with private subnets, and demonstrated the resources required to deploy a serverless Aurora RDS instance with security groups ready to be attached to any additional resources that required database access.

We have other posts about CloudFormation templates you might find helpful too.

Follow our series about Runbooks

We're focusing on Runbooks for a few months this year. We’ll include a summary of the blog posts in our monthly newsletter. Sign up to follow along.

Happy deployments!
